Precision filter
关注度: 3469
产品概要：
零售价
0.0
元
市场价
0.0
元
Precision filter，Low-pressure precision filter gland filter air processing capacity from 1m3-30m3, from general to precision to ultra-precision, and activated carbon filters.
QQ咨询所属分类
Low Pressure Style
数量
-
+
库存:
0
33434343 222
1
产品描述
参数
Low-pressure precision filter gland filter air processing capacity from 1m3-30m3, from general to precision to ultra-precision, and activated carbon filters.
法兰式精密过滤器参数
| 型号 | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | YDF- | |
| 1 | 2 | 3 | 6 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 150 | 200 | ||
| 额定处理量 | 1 | 2 | 3 | 6 | 12 | 20 | 30 | 40 | 60 | 80 | 100 | 150 | 200 | |
| 进出口通径 DN-MM | 20 | 25 | 40 | 40 | 50 | 65 | 80 | 100 | 100 | 125 | 150 | 200 | 250 | |
| 外形尺寸 | 气口间距 | 150 | 190 | 200 | 220 | 220 | 400 | 450 | 450 | 500 | 550 | 650 | 650 | 800 |
| mm | 高度 | 580 | 650 | 680 | 820 | 930 | 1250 | 880 | 1250 | 1250 | 1250 | 1250 | 1250 | 1250 |
